Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8" UNI-T
Product Code: MSO2204
The photo is for illustration only. Please refer to the description for exact product specifications.
Delivery terms
2025-07-18 Estimated delivery
Product will be ordered from supplier. If the supplier is unable to deliver by the specified date, we will inform you by e-mail
 1 pcs | Supplier Warehouse |
Home delivery
Home delivery
After handing over the goods to the courier, we will inform you by e-mail. If you are ordering outside of Estonia please use www.lemona-electronics.eu to order.
Over €50.00 (Orders up to 1000 kgs) | For free |
To €50.00 (Orders up to 1000 kgs) | €5.00 |
Delivery to DPD pickup locations
Delivery to DPD pickup locations
After handing over the goods to the courier, we will notify you by e-mail. Free delivery for orders over 50€.
3,50
Product description
Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8" UNI-T
Useful information
Specifications
Supplier product description
Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Useful information
Supplier parameters
Product code
MSO2204
Supplier's product code
MSO2204
Product ID
U-3845386
Band
200MHz
Dimensions
370x185x115mm
Display resolution
800x480
Input coupling
AC, DC, GND
Input impedance
1MΩ/16pF
Input sensitivity
500µV/div...20V/div
Interface
LAN
Kind of display used
LCD TFT 8"
Manufacturer
UNI-T
Measuring instrument features
mathematical functions: addition, subtraction, division, multiplication and FFT
Memory record length
56Mpts
Number of channels
4
Related items
MSO/UPO2000-AUTO
Rise time
≤1.8ns
Sampling
2 Gs/s
Standard equipment
USB cable
Supply voltage
100...240V AC
Time base
1n...1ks/div
Type of oscilloscope
digital
Trigger
video signal
Vertical resolution
8bit
Brand
UNI-T
The information that supplier provides may differ from the actual product. If you noticed an error please let us know by email: [email protected].
