Product description
Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; NA FCL Components
Useful information
Specifications
Supplier product description
Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; NA
Useful information
Supplier parameters
Product code
NAL-12W-K
Brand
FCL Components
Supplier's product code
NAL-12W-K
Product ID
U-2180906
AC contacts rating @R
0.5A / 125V AC
Coil power consumption
100mW
Coil resistance
1.44kΩ
Coil voltage min.
9V DC
Contact current max.
2A
Contact material
AgPd/Au 0,2μm
Contacts configuration
DPDT
DC contacts rating @R
1A / 30V DC
Manufacturer
FCL Components
Manufacturer series
NA
Mounting
PCB
Operate time
6ms
Operating temperature
-40...85°C
Rated coil voltage
12V DC
Relay variant
subminiature
Release time
6ms
Switched voltage
max. 220V DC
Terminal pitch
2.54mm
Type of relay
electromagnetic
The information that supplier provides may differ from the actual product. If you noticed an error please let us know by email: [email protected].
