Uninterruptible Power Supply NANO 600VA 360W, Offline, FSP
Pickup in department 1-5 b.d.
 >10 pcs | Central Warehouse |
 Not available | Tallinn Office |
Home delivery 1-5 b.d.
Delivery to DPD Pickup locations 1-5 b.d.
Delivery terms
Pickup in department
Pickup in department For free
Quantity in shop
| >10 pcs | Central Warehouse |
| Not available | Tallinn Office |
Home delivery
Home delivery
After handing over the goods to the courier, we will inform you by e-mail.
Over €25.00 (Orders up to 1000 kgs) | For free |
To €25.00 (Orders up to 1000 kgs) | €4.50 |
Delivery to DPD pickup locations
Delivery to DPD pickup locations
€3.50
Product description
Features
- Compact size with stand and mounting flexibility
- Excellent microprocessor control guarantees high reliability
- Auto restart while AC is recovering
- Simulated sine wave
- Cold start function
- Full protection: discharge, overcharge, short circuit, and thermal protection
- Off-line technology
- Automatic switch-on when the power supply is restored
- Simple and easy installation and operation
Technical data
| MODEL | NANO 400 | NANO 600 | NANO 800 |
| PHASE | Single phase | ||
| CAPACITY | 400VA / 240W | 600VA / 360W | 800VA / 480W |
| PARALLEL CAPABILITY | NO | ||
| INPUT | |||
| Nominal Voltage | 220V/230V/240V AC | ||
| Voltage Range | 180-270 Vac | ||
| Frequency Range | 50Hz (auto sensing) | ||
| Power Factor | - | ||
| OUTPUT | |||
| Output Voltage | - | ||
| AC Voltage Regulation (Batt. Mode) | ± 10% | ||
| Frequency Range (Synchronized Range) | - | ||
| Frequency Range (Batt. Mode) | 50Hz ±1 Hz | ||
| Current Crest Ratio | - | ||
| Harmonic Distortion | - | ||
| Transfer time AC mode to Battery mode | Typical 2-6 ms | ||
| Transfer time Inverter to Bypass | - | ||
| Waveform (Batt. Mode) | Simulated Sine Wave | ||
| Overload AC Mode | - | ||
| Overload Battery Mode | - | ||
| EFFICIENCY | |||
| AC Mode | - | - | - |
| ECO Mode | - | - | - |
| Battery Mode | - | - | - |
| BATTERY | |||
| Battery Type | 12V / 4.5Ah | 12V / 7Ah | 12V / 9Ah |
| Numbers | 1 | 1 | 1 |
| Typical Recharge Time | 8 hours recover to 90% capacity | ||
| INDICATORS | |||
| AC mode | Green lighting | ||
| Battery mode | Green flashing | ||
| ALARM | |||
| Battery mode | Sounding every 10 seconds | ||
| Low battery | Sounding every second | ||
| Overload | - | ||
| Fault | Continuosly sounding | ||
| PROTECTION | |||
| Full Protection | Overload, discharge and overcharge protection | ||
| PHYSICAL | |||
| Dimension, D X W X H (mm) | 228 x 82.5 x 207 (Vertically stand) | ||
| Net Weight (kgs) | 2.2Kg | 2.7Kg | 3.1Kg |
| ENVIRONMENT | |||
| Operation Temperture | 0-40°C | ||
| Operation Humidity | 0 - 90 % and non-condersing | ||
| Noise Level | Less than 40dB @ 1 meter | ||
| MANAGEMENT | |||
| Smart RS-232/USB | - | ||
| Optional SNMP | - | ||
| Product specifications are subject to change without further notice | |||
