Kauba kirjeldus
"EasySolar combines the MPPT solar charge controller, inverter/charger and AC distribution in one housing. The product is easy to install with minimal wiring.
Features
All-in-one solar power solution
"EasySolar combines theMPPT solar charge controller, inverter/charger and AC distribution in a single housing. The product is easy to install with minimal wiring.
Solar charge controller: Blue Solar MPPT 100/50
Up to three strings of PV panels can be connected to the three MC4(PV-ST01) PV connector sets.
MultiPlus Compact 12/1600/70 or 24/1600/40
The MPPT charger and the MultiPlus Compact inverter/charger use DC battery cables (included).The batteries can be recharged using solar energy (BlueSolar MPPT) and/or AC energy (inverter/charger) from the grid or a generator.
AC power distribution
The AC distribution consists of an RCD (30 mA / 16 A) and four AC outputs protected by two 10A and two 16A circuit breakers.
One 16A output is controlled by an AC input: it will only switch on when AC is present.
"PowerAssist
Unique "PowerAssist" technology protects the utility or generator supply from overload by adding additional inverter power when needed.
Unique solar application software
Several software applications (assistants) can be used to configure the system for different grid interactive or stand-alone applications.
VictronEnergy brand
Manufacturer number CEP121620000
Voltage 12V
Transfer switch 16A
Continuous output power at 25°C 1600VA / 1300W
Maximum output 3000W
Charger current house battery 70A
Battery temperature sensor Yes
Programmable relay Yes
Ingress protection IP22
Battery connection: 1.5m battery cables
Dimensions (including terminals) H745 x W214 x D110mm
Weight 15kg
Warranty 5 years
Country of manufacture: China
The description was translated using an automatic translator. If you notice any discrepancies, please notify us by email: [email protected].
Tehnilised andmed
Tarnija toote kirjeldus
The EasySolar combines a MPPT Solar Charge Controller, an inverter/charger and AC distribution in one enclosure. The product is easy to install, with a minimum of wiring.
